Description of product characteristics:
*Widely used in small and medium-sized transformers, relays, precision coils, high-voltage wire packages, power adapters, stabilizers and other products.
*CNC controller is adopted, AC motor and stepping motor perform precise motion, external multi-channel function control can be connected, and the application is stable.
*Data teaching type-in, easy to operate, easy to maintain, imported accessories, process quality control, stable and reliable equipment.
*According to the need to change the program to achieve multi-function, pause editing, deceleration at both ends, counting method, starting method, speed limit and other function selection.
*The advanced control circuit has strong anti-interference, overload-overcurrent protection, and adopts switching power supply control to adapt to the working voltage bandwidth.
*The machine can be connected with the safe automatic stop control, and the position of the winding axis can be set with the following function to assist the winding point and width position setting.
*0-999 sets of step sequence setting storage, with frequency conversion AC motor and precision stepping motor, can easily set forward and reverse rotation, cross slot and flow tight winding.
Technical parameters:
| Model No | LX-044 | |||||||||
| Spindie number | 4 | |||||||||
| Spindle diameter/MM | 12 | |||||||||
| Wire size/MM | 0.02-0.6 | |||||||||
| Max.Speed/RPM | 5200 | |||||||||
| Main Motor | AC/370W | |||||||||
| Winding With/MM | 70 | |||||||||
| Spreading Motor | 9V(Stepping Motor) | |||||||||
| Spreading Width/MM | 100 | |||||||||
| Working voltage | 220V-AC | |||||||||
| Weight/KG | 80 | |||||||||
| Dimensions L*W*H/MM | L/1000*W/680*H/1000 | |||||||||
